Beechcraft Model 18

Douglas C-47A Dakota and Beech 18 Classic Formation
Douglas C-47A Dakota and Beech 18 Classic Formation

The Beechcraft Model 18 (or Twin Beech”, as it is also known) is a 6- to 11-seat, twin-engined, low-wing, tailwheel light aircraft manufactured by the Beech Aircraft Corporation of Wichita, Kansas. Continuously produced from 1937 to November 1969 (over 32 years, a world record at the time), over 9,000 were built, making it one of the world’s most widely used light aircraft. Sold worldwide as a civilian executive, utility, cargo aircraft, and passenger airliner on tailwheels, nosewheels, skis, or floats, it was also used as a military aircraft.

Role Trainer, transport aircraft and utility aircraft
National origin United States
Manufacturer Beech Aircraft Corporation
First flight January 15, 1937
Introduction 1937
Primary users United States Army Air Forces
United States Navy
Royal Air Force
Royal Canadian Air Force
Produced 1937–1970
Number built 9,000+

Specifications (UC-45 Expeditor)

General characteristics

  • Crew: 2 pilots
  • Capacity: 6 passengers
  • Length: 34 ft 3 in (10.44 m)
  • Wingspan: 47 ft 8 in (14.53 m)
  • Height: 9 ft 9 in (2.97 m)
  • Wing area: 349 sq ft (32.4 m2)
  • Empty weight: 5,420 lb (2,458 kg)
  • Gross weight: 7,500 lb (3,402 kg)
  • Powerplant: 2 × Pratt & Whitney R-985-AN-1 “Wasp Junior” radial engines, 450 hp (340 kW) each

Performance

  • Maximum speed: 225 mph (362 km/h, 196 kn)
  • Range: 1,200 mi (1,900 km, 1,000 nmi) at 160 mph (260 km/h; 140 kn) and 5,000 ft (1,500 m)
  • Service ceiling: 26,000 ft (7,900 m)
  • Rate of climb: 1,850 ft/min (9.4 m/s)

Photos Rob Vogelaar and Marcel van Leeuwen
